Product model
|
Frequency range
|
Standing-wave ratio
|
Installation hole spacing
|
Installation method
| Expose the diameter of the inner conductor |
Specification
|
|---|---|---|---|---|---|---|
| SMA-KHD95 | DC-18GHz | 1.25 | 9.5mm | The outer conductor is free of welding, and the center pin needs to be welded | 1.0mm |
|
| SMA-KHD95-1 | DC-18GHz | 1.25 | 9.5mm | The outer conductor is free of welding, and the center pin needs to be welded | 0.75mm |
|
| SMA-KHD95-2 | DC-18GHz | 1.25 | 9.5mm | The outer conductor is free of welding, and the center pin needs to be welded | 1.38mm |
|
SMA-KFED-13 |
DC-27GHz |
1.25 |
9.5mm |
Edge clamp without welding | 0.13mm |
|
SMA-KFED-18 |
DC-27GHz |
1.25 |
9.5mm | Edge clamp without welding | 0.18mm |
|
SMA-KFED-25 |
DC-27GHz |
1.25 |
9.5mm |
Edge clamp without welding | 0.25mm |
|
SMA-JFED-13 |
DC-27GHz |
1.25 |
9.5mm |
Edge clamp without welding
| 0.13mm |
|
SMA-JFED-18 |
DC-27GHz |
1.25 |
9.5mm |
Edge clamp without welding | 0.18mm |
|
| SMA-JFED-25 | DC-27GHz | 1.25 | 9.5mm | Edge clamp without welding | 0.25mm |  |
| 2.92-KFED-13 | DC-40GHz | 1.25 | 9.5mm | Edge clamp without welding | 0.13mm |  |
| 2.92-KFED-18 | DC-40GHz | 1.25 | 9.5mm | Edge clamp without welding | 0.18mm |  |
| 2.92-KFED-25 | DC-40GHz | 1.25 | 9.5mm | Edge clamp without welding | 0.25mm |  |
| 2.92-JFED-13 | DC-40GHz | 1.25 | 9.5mm | Edge clamp without welding | 0.13mm |  |
| 2.92-JFED-18 | DC-40GHz | 1.25 | 9.5mm | Edge clamp without welding | 0.18mm |  |
| 2.92-JFED-25 | DC-40GHz | 1.25 | 9.5mm | Edge clamp without welding | 0.25mm |  |
| 2.4-KFED-13 | DC-50GHz | 1.30 | 9.5mm | Edge clamp without welding | 0.13mm |  |
| 2.4-KFED-18 | DC-50GHz | 1.30 | 9.5mm | Edge clamp without welding | 0.18mm |  |
| 2.4-KFED-25 | DC-50GHz | 1.30 | 9.5mm | Edge clamp without welding | 0.25mm |  |
| 2.4-JFED-13 | DC-50GHz
| 1.30 | 9.5mm | Edge clamp without welding | 0.13mm |
|
| 2.4-JFED-18 | DC-50GHz | 1.30 | 9.5mm | Edge clamp without welding | 0.18mm |
|
| 2.4-JFED-25 | DC-50GHz | 1.30 | 9.5mm | Edge clamp without welding | 0.25mm |
|
| 1.85-KFED-13
| DC-65GHz | 1.35 | 9.5mm | Edge clamp without welding | 0.13mm |
|
| 1.85-KFED-18 | DC-65GHz | 1.35 | 9.5mm | Edge clamp without welding | 0.18mm |
|
| 1.85-JFED-13 | DC-65GHz | 1.35 | 9.5mm | Edge clamp without welding | 0.13mm |
|
| 1.85-JFED-18 | DC-65GHz | 1.35 | 9.5mm | Edge clamp without welding | 0.18mm |
|
