Product model
|
Frequency range
|
Standing-wave ratio
|
Inner conductor diameter Φ D
|
Exposed inner conductor length L |
Flange hole spacing
|
Specification
|
|---|---|---|---|---|---|---|
|
1.85-KFD0101-23GS
|
DC-65GHz
|
1.25
|
0.23mm
|
7mm
|
Two holes/8.6mm
|
|
|
1.85-KFD0101-30GS
|
DC-65GHz
|
1.25
|
0.30mm
|
2mm
|
Two holes/8.6mm
|
|
|
1.85-KFD0101-58GS
|
DC-65GHz
|
1.25
|
0.58mm
|
3.7mm
|
Two holes/8.6mm
|
|
|
1.85-KFD0101-64GS
|
DC-65GHz
|
1.25
|
0.64mm
|
6mm
|
Two holes/8.6mm
|
|
|
1.85-KFD0101-80GS
|
DC-65GHz
|
1.25
|
0.80mm
|
7mm
|
Two holes/8.6mm
|
|
| 1.85-KFD0901-23GS | DC-65GHz | 1.25 | 0.23mm | 7mm | Two holes12.2mm |  |
| 1.85-KFD0901-30GS | DC-65GHz | 1.25 | 0.30mm | 2mm | Two holes12.2mm |
|
| 1.85-KFD0901-58GS | DC-65GHz | 1.25 | 0.58mm | 3.7mm | Two holes12.2mm |
|
| 1.85-KFD0901-64GS | DC-65GHz | 1.25 | 0.64mm | 6mm | Two holes12.2mm |
|
| 1.85-KFD0901-80GS | DC-65GHz | 1.25 | 0.80mm | 7mm | Two holes12.2mm |
|
| 1.85-KFD0201-23GS | DC-65GHz | 1.25 | 0.23mm | 7mm | Four holes/8.6mm |
|
| 1.85-KFD0201-30GS | DC-65GHz | 1.25 | 0.30mm | 2mm | Four holes/8.6mm |
|
| 1.85-KFD0201-58GS | DC-65GHz | 1.25 | 0.58mm | 3.7mm | Four holes/8.6mm |
|
| 1.85-KFD0201-64GS | DC-65GHz | 1.25 | 0.64mm | 6mm | Four holes/8.6mm |
|
| 1.85-KFD0201-80GS | DC-65GHz | 1.25 | 0.80mm | 7mm | Four holes/8.6mm |
|
